Sale – Leica BLK3D

Leica BLK3D

Leica BLK3D is a real-time, in-picture 3D measurement solution. By combining measurement sensors, software, and on-device edge data processing capabilities, the Leica BLK3D makes in-picture measurements with professional-grade accuracy in real-time possible. Every image captured is a complete and precise 3D measurement record. Its edge computing capabilities eliminate the need for network connections and cloud services, ensuring professionals can make faster decisions within their daily workflows – whether measuring inaccessible locations, creating floor plans, estimating building installations, documenting construction site progress or creating measurable, as-built documentation.

Take a picture. Measure anything: The BLK3D captures images and places precise measurements at your fingertips. Share images and measurements in multiple formats.
The art of photogrammetry. Simplified: Un-matched combination of a calibrated stereo-camera, advanced algorithms and real-time edge computing fused with leading Electronic Distance Measurement (EDM) technology.
Access projects. Anywhere, anytime: Measure in your image – on the handheld imager, on the desktop, on-site or in the office.
Working with digital floorplans: Create floorplans and import existing ones. Add measurable images. Document construction progress with multiple images over time.
New dimensions for 2D pictures: The BLK3D creates images that contain precise three-dimensional measurements.
Progressive project documentation for AEC: Capture critical moments throughout the life of a building.
Object detection and snapping: Auto-Snapping uses computer vision technologies to select the right points for your measurements.
Store. Organize. Share.: Store your measurable images on the device and on desktop. Organize your projects by tagging measurable images with searchable keywords for easy recall and share them in multiple formats

BLK3D ACCURACY: The BLK3D represents a new way to capture and document reality by combining measurement sensors, software, and on-device data processing. Its integrated stereo-camera captures images that provide a complete 3D record, with EDM accuracy of 1mm*, 2D in-picture accuracy of +/- 3mm*, 3D in-picture accuracy of +/- 6mm

Home Global Atlas sell Leica BLK3D with best quality product

Leica BLK3D 3D Measurement

SPESIFICATION

Design & Physical Dimensions

Material: Black anodized aluminium
Dimensions: 180mm x 77mm x 27mm
Weight: 480g
Connector: USB-C
Display: 5’’ HD IPS Capacitive Touch Display
P2P Support: Quick Mount on Leica DST 360

Power

Battery Type: Swappable, rechargeable Li-Ion battery
Capacity: 14 Wh
Charging: via USB-C connector or external charger

Environmental

Robustness: Designed for any construction site
Operating Temperature: -10°- +50°C

Imaging

Camera: 2 x 10MP with 80°Field of View
Algorithms: Advanced SGM algorithmic on-board (GPU) + EDM, Structure from Motion (SFM) algorithmic for poses and orientation

Operating System & Processors

Operating System: Android 7 (Nougat) with GMS certification
CPU: Qualcomm Snapdragon 820E (Quad Core @ 2.35 GHz)
Storage: 64G
RAM : 4GB
Communication: WLAN (5GHz), Bluetooth 4.1 and 2.1

Performance

Measurement Speed: <1 sec
Range: up to 20m (imaging); 250m (Electronic Laser Distance Measurement)
