Sale – Nidek OPD-Scan III

Nidek OPD-Scan III

Nidek OPD-Scan III is an autorefractor, keratometer, pupillometer (up to 9.5mm), corneal topographer, and integrated wavefront aberrometer. The OPD-Scan III completes 20 diagnostic metrics in less than 10 seconds per eye (including angle kappa, HOAs, average pupil power, RMS value, and point spread function).

Easy alignment and automatic capture of wavefront aberrometry data ensures accurate readings. Wavefront aberrometry data is gathered from available zones up to a 9.5mm area, adding the capability to provide for calculation of mesopic refractions. Blue light, 33 ring, placido disc topography is gathered in one second. Mapping methods include OPD, visual acuity corneal topography/topographer

Next Generation of Refractive Eye Care

The unique Nidek OPD-Scan III Corneal Analyzer is an advanced vision assessment system that combines topography, wavefront, automated refractor, keratometry, and pupillometry

Make Optimal Decisions Easily

The OPD-Scan offers multiple map summaries to suit you practice or clinical requirements with easy-to-understand patient reports and even more details for comprehensive vision analysis

Enhanced Patient Comfort

33 blue placido mires provide a minimum of 11,880 data points which is more than 170% of the OPD-Scan II. The blue wavelength allows greater precision in ring detection. The reduced illumination creates a comfortable patient experience.

Outcome Simulation of Postoperative Corneal Shape and Total Eye Refraction

The optional Final Fit software evaluates and converts the OPD-Scan III refractive and topographic data to produce the precise customized ablation parameters for the NIDEK EC Quest Excimer Laser System

Accurate Diagnostics

Over 20 diagnostic measurements are acquired in 10 seconds. Easy alignment and automatic capture of data ensures accurate readings. Wavefront data is gathered from available zones up to a 9.5mm area, adding the capability to provide for calculation of mesopic refractions. Blue light, 33 ring, placido disc topography is gathered in one second

Home Global Atlas sell Nidek OPD-Scan III with best quality product

Data View Options

Axial, gradient, instantaneous, numeric K display, numeric power display, PSF (point spread function), zernike graph (including corneal), contact lens summary, VA-ETDRS simulations, internal OPD, eye image, comparison maps, and difference maps

Dysfunctional Lens Syndrome (DLS)

The above map is a measurement of a prior myopic LASIK patient with Dysfunctional Lens Syndrome (DLS). The Point Spread Function (PSF) maps show that the cornea is contributing to the problem but the majority of the patient’s issue is lenticular change. The patient thought she needed another LASIK treatment, when in actuality, the lens changed

Day/Night Wavefront Refractions

This provides information on the stability of the refractive error as pupil size changes, and the individual starting points for separate day and night refractions, if indicated. Your patients can receive a state of the art printout of their ‘before’ and ‘after correction’ chart or understand why they are not able to achieve 20/20. Welcome to the next generation of refractive eye care.

Captured In 10 Seconds

Corneal SA for Aspheric IOL Selection
Lenticular – Residual Astigmatism
Angle Kappa/Angle Alpha
Pre/Post Toric IOL Measurements
Pathologies (Keratoconus, Pellucid)
Mesopic/Photopic Pupil Size
Retro Illumination Image
Zernike Graphs: Total, Cornea, Internal
Corneal Refractive Power Map
IOL Tilt Eye Image or Decentration

TECHNICAL DETAILS
Power Mapping
Spherical Power Range -20.00 to +22.00 D
Cylindrical Power 0.00 to ±12.00 D
Axis 0 to 180°
Measurement Area 2.0 to 9.5 mm (7 zone measurement)
Data Points 2,520 points (7 x 360)
Measuring time < 1.0 seconds
Measurement Method Automated objective refraction (dynamic skiascopy)
Mapping Methods OPD, Internal OPD, Wavefront maps, Zernike graph, PSF, MTF graph, Visual Acuity Corneal Topography
Measurement Rings 33 vertical, 39 horizontal
Measurement Area 0.5 to 11.0 mm (r = 7.9)
Dioptric Range 33.75 to 67.5 D
Axis Range 0 to 359˚
Data Points More than 11,880
Mapping Methods Axial, Instantaneous, “Refractive”, Elevation, Wavefront maps, Zernike graph, PSF, MTF graph, Visual Acuity General Information
Working Distance 75 mm
Auto Tracking X-Y-Z directions
Observation Area 14 x 11 mm
Specifications
Operating System OPDIII Windows 10
Display 10.4-inch color LCD touch panel
Printer Built-in thermal type line printer for data print External color printer (optional) for map print
Power Supply 100 to 240 Vac 50 / 60 Hz
Power Consumption 110 VAC
Dimensions
Measurements 286 (W) x 525 (D) x 530 (H) mm
Mass 23kg

Nidek OPD Scan III Corneal Analyzer Wavefront Aberrometer, Topographer and Visual Function Device. Featuring 2520 aberrometry measurements, over 11,000 topography measurements, photopic and mesopic pupillometry, lenticular retroillumination, a toric lens planning tool, and visual simulations replicating photopic or mesopic conditions.
