High Voltage VLF-4022CM

High Voltage VLF-4022CM, there is only one sure way to know: VLF IT! The best way toexpose defects in a cable is to AC hipot it using VLF technology.After any cable is installed or repaired, it should be VLF hipotted to insure the integrity of the insulation, splices, joints, etc.The cable’salready down:VLF it before reenergizing.If the cable can’t hold 2 –3 times normal voltage for the IEEE prescribed 15 minutes,findout now while you’re there to make the repairs.

The High Voltage VLF-4022CM 40kV AC VLF Hipot is a Very Low Frequency AC high voltage test system – a 0 – 40kV AC VLF Hipot.

Home Global Atlas sell High Voltage VLF-4022CM with best quality product

Features:

40kV VLF Hipot
Output voltage is 0-40 kVac peak, 0.1 / 0.5 / 0.02 Hz sinusoidal
Load rating: 1.1μF @ 0.1 Hz, 2.2μF @ 0.05 Hz, & 5.5μF @ 0.02 Hz
Capable of testing 25kV cable up to a maximum distance of 10 Miles (depending on type)
Metering: Voltmeter -40 – 0 – +40kVac, Charging current meter 0-100mA, and capacitance meter 0-6 μF
Charging current and load capacitance meter included
Two piece design

Specifications
Input: 120 V, 60 Hz, 5 A peak, 2.5 A average
(F) 230 V, 50/60 Hz, 3 A peak, 2 A average
Output: 0 – 44 kV AC peak, 0.1/0.05/0.02 Hz sinusoidal
Duty: Continuous
Load Rating: 1.1 µF @ 0.1 Hz
2.2 µF @ 0.05 Hz
5.5 µF @ 0.02 Hz
Voltmeter: Center zero -45 – 0 – +45 kV AC peak
Current Meter: 0 – 100 mA peak
Load Capacitance Meter: 0 – 6 µF
Output Termination: Shielded RG/8U output cable – 20 ft. (6 m)
Interconnect cable – 10 ft. (3 m)
Size & Weight:
(W x D x H) Controls:
22 x 11.25 x 15.25 in., 50 lb.
559 x 286 x 387 mm, 23 kg
HV Tank:
14.5 x 10.5 x 19 in., 72 lb.
368 w x 267 d x 483 mm, 33 kg

VLF-4022CM has a 44 kVac peak output suitable for testing cables rated up to 25 kV. Its high load capacity can test over 10 miles (16 km) of cable, depending on type. This model includes a charging current and load capacitance meter, and a center zero peak kilovolt output meter. Two-piece construction makes it easy to transport and store.
